Case studies
Tarporley 2x Vaillant ASHP
Poulton-Le-Flyde UFH & Screed
Poulton-Le-Flyde UFH & Screed
Niche Energy Solutions fitted 2x 12kW Valliant Air Source Heat Pump's in Tarporley
Poulton-Le-Flyde UFH & Screed
Poulton-Le-Flyde UFH & Screed
Poulton-Le-Flyde UFH & Screed
A beautiful home in Poulton-Le-Flyde where Niche installed 5 manifold's and covered 500m2 of surface area.
Mosque, Bolton
Runcorn, Halton
Runcorn, Halton
500m2 mosque in Bolton with our underfloor heating pipe spacing at 150mm centres in readiness for an air source heat pump and 30m3 of gypsum based floor screed.
Runcorn, Halton
Runcorn, Halton
Runcorn, Halton
Our Proline System was utilised on 4 of these new build property's in Tattenhall. 13m3 of Anhydrite screed was supplied at 50mm depth.
Our pipe was spaced at 150mm with a 11 port Manifold on the GF and a 12 port Manifold on the FF.
Treaddur Bay, North Wales
Treaddur Bay, North Wales
Treaddur Bay, North Wales
Newly built 6 bedroom holiday let cottage in the picturesque Treaddur Bay. In this stunning property we supplied and installed 17m3 of our rapide fast drying screed and underfloor heating over the two floors.
Holmfirth, Huddersfield
Treaddur Bay, North Wales
Treaddur Bay, North Wales
Barn conversion lovingly renovated to a high standard. This property benefited from our Gypsum based screed and underfloor heating system designed by ourselves over two floors generating warmth and comfort throughout the year.
Heswall, Wirral
Corwen, North Wales
Corwen, North Wales
A new build project creating modern apartments and office space. We supplied and installed 31m3 of Cementitious liquid screed and over 3 floors and 579m2 of underfloor heating pipe.
Corwen, North Wales
Corwen, North Wales
Corwen, North Wales
Lovely new build property in Corwen, North Wales. Benefiting from our turnkey solution of insulation, underfloor heating, screed + a ground source heat pump and plumbing service. Total screed installed 28m3 over 350m2 utilising over 3km of underfloor heating pipe and 1.6km of geo thermal ground collector pipe. Cost effective heating solution to a large country property.
Ground source heat pump
Rufford Primary School
Last summer Niche supplied and installed 2x Stiebel Eltron 44kW Ground Source Heat Pump at Rufford Primary School. The process involved excavating the ground to create a series of trenches and drilling deep bore holes to access the earth's natural heat. This was a crucial step in the installation of the heat pump system, which utilizes renewable energy to heat the school. The project not only helped to reduce the school's carbon footprint but also demonstrated Niche's commitment to sustainable construction practices.
Bolton Le Sands
Niche supplied and installed a 44kW and a 59kW Stiebel Eltron Ground Source Heat Pump in Bolton Le Sands Primary School last summer. This involved digging 10 bore holes, each 125 meters deep, to access the earth's natural heat. The heat pumps utilize renewable energy to provide heating and hot water to the school, making it more energy-efficient and environmentally friendly. The project not only reduced the school's carbon footprint but also helped to lower its energy bills.
Chorley Primary
Niche supplied and installed 2x 60kW Stiebel Eltron Ground Source Heat Pump at Chorley Primary School last summer. This involved digging 7 bore holes, each 125 meters deep, with also digging 15 Trenches to access the earth's natural heat. GSHPs are one of the most energy-efficient heating and cooling systems available. They can provide several units of heating or cooling for every unit of electricity used to operate the system. This high efficiency leads to reduced energy consumption and lower utility bills.
5 TCAT Warrington Schools
Niche achieved a successful decarbonisation project on five schools in Warrington. Through a comprehensive and forward-thinking approach to sustainability, Niche has implemented cutting-edge technologies and eco-friendly solutions aimed at reducing carbon emissions and promoting energy efficiency. The decarbonization efforts have encompassed a range of initiatives, from upgrading old heating systems to incorporating renewable energy sources. This accomplishment underscores the positive impact that dedicated efforts toward decarbonization can have on both local communities and the broader goal of mitigating climate change.
